Renault Group - Specific datalogging

Autotuner now offers specific datalogging for the Renault group. Unlike generic datalogging based on OBD-II standard codes, specific datalogging relies on manufacturer-defined codes.

On the following ECUs:

      • Bosch : EDC16CP42 / EDC17C11 / EDC17C42 / EDC17C84 / EDC17CP19 / EDC17CP58 / MD1CS006 / MD1CS016 / ME17.7.20 / ME17.9.20 / ME17.9.23
      • Continental : EMS3110 / EMS3125 / EMS3140 / EMS3141 / EMS3150 / EMS3155 / EMS3160 / EMS3161 / EMS3180 / SID307 / SID309 / SID310 / SID321
      • Delphi : DCM3.4
      • Hitachi : BED434 / BED436 / BED501
      • Sagem : S3000
      • Siemens : SID305 / SID306
      • Valeo : V40 / V50.1

Measured data:

AIR

  • Atmospheric pressure
  • Camshaft position
  • Mass air flow
  • Mass air flow setpoint

BASICS

  • Engine speed
  • Gas pedal position
  • Gear
  • Vehicle speed

BOOST

  • Boost pressure
  • Boost pressure setpoint
  • Wastegate duty

EMISSIONS

  • Distance after successful regeneration
  • EGR rate
  • Is regen active ?
  • Particulate filter differential pressure
  • SCR tank level
  • Soot mass

FUEL

  • Fuel high pressure
  • Fuel high pressure setpoint
  • Fuel low pressure
  • Fuel low pressure setpoint
  • Fuel pressure regulator

IGNITION

  • Ignition advance timing
  • Ignition withdrawal
  • Knock counter

INJECTION

  • Injection advance
  • Injection duration
  • Lambda
  • Lambda setpoint
  • Main injection quantity
  • Long term fuel trim
  • Short term fuel trim

LOAD / TORQUE

  • Absolute Load value
  • Engine torque
  • Gearbox torque limitation
  • Max engine torque
  • Throttle valve position
  • Torque limitation

TEMPERATURE

  • Atmospheric air temperature
  • Engine coolant temperature
  • Engine oil temperature
  • Exhaust gas temperature
  • Intake air temperature
